- 9,600
- Max towing, lbs
- 6,000
- Lowest rating, lbs
- 6
- Configurations
- 700
- Max tongue, lbs
Try it
Will it pull your trailer?
Use the trailer's GVWR (on its VIN sticker) if you don't know what it weighs loaded — the dry weight leaves out water, propane and gear.
Yes, in every configuration
Across all 6 configurations in the maker's guide.
▲ top rating 9,600 lbs
- Tongue weight ≈ 530 lbs. Ford sizes it at 10% of the loaded trailer (no more than 200 lbs up to 2,000 lbs). It counts against your payload, together with passengers and cargo.
- ✓ up to 90% of the rating · ! 90–100% (little room for cargo, hills, wind — common advice, not a Ford rule) · ✕ over the rating.
Read this before you buy
Why the numbers differ
The body style counts too: Expedition (SWB) is rated 600 lbs higher than Expedition MAX (LWB) with everything else the same (3.5L EcoBoost V6 · 3.73 axle · Expedition (SWB) · 4x4 · Automatic). p. 38 ↗
Same top rating as the 2025 model (9,600 lbs).
In real life
What 9,600 lbs means in trailers
Ford's own guide sorts trailers into four classes. With the right configuration the Expedition reaches:
- Class I✓ Yes
up to 2,000 lbs
Small folding camping trailers and trailers for small boats, motorcycles and snowmobiles.
- Class II✓ Yes
2,001–3,500 lbs
Large folding camping trailers, single-axle, small- to medium-length (up to 18-ft.) trailers.
- Class III✓ Yes
3,501–5,000 lbs
Dual-axle or large single-axle travel trailers.
- Class IVUp to 9,600
over 5,000 lbs
Largest travel and 5th-wheel trailers made for recreation.
Real trailers
Can the Expedition pull these?
Similar boat package, not this model.Photo: Airman Nicole Sikorski, Public domain, via Wikimedia Commons
G3 Boats · boat package · 23 ft
Sportsman 1710 (boat + motor + trailer package)
1,865 lbs boat + motor + trailer, before fuel and gear
✓ Any configuration
Similar utility, not this model.Photo: Xaver X. Dreißig, CC BY-SA 4.0, via Wikimedia Commons
Carry-On Trailer · utility · 11.54 ft
5' x 8' GW2K Series 5X8GW2K (open utility, wood floor, gate)
2,000 lbs GVWR (max loaded)
✓ Any configuration
nuCamp · teardrop · 15.5 ft
TAB 320 (Boondock)
2,069 lbs dry weight only — loaded will be more
✓ Any configuration
Similar cargo, not this model.Photo: DiamondBack Covers, CC BY-SA 2.0, via Flickr
Carry-On Trailer · cargo · 12 ft
5' x 8' CG3K Series 5X8CG (enclosed cargo, single rear door)
2,990 lbs GVWR (max loaded)
✓ Any configuration
Similar travel trailer, not this model.Photo: Olgierd Rudak, CC BY-SA 4.0, via Wikimedia Commons
Airstream · travel trailer · 20.17 ft
Basecamp 20X
4,300 lbs GVWR (max loaded)
✓ Any configuration
Similar travel trailer, not this model.Photo: Anshamblen15, CC BY-SA 4.0, via Wikimedia Commons
Jayco · travel trailer · 20.17 ft
Jay Feather Air 16RB
4,995 lbs GVWR (max loaded)
✓ Any configuration
Similar travel trailer, not this model.Photo: Olgierd Rudak, CC BY-SA 4.0, via Wikimedia Commons
Airstream · travel trailer · 20.58 ft
Bambi 20FB
5,000 lbs GVWR (max loaded)
✓ Any configuration
Similar travel trailer, not this model.Photo: Anshamblen15, CC BY-SA 4.0, via Wikimedia Commons
Jayco · travel trailer · 29.42 ft
Jay Flight SLX 260BH
6,500 lbs GVWR (max loaded)
! 4 of 6 configurations
Needs the 3.5L EcoBoost V6.
Similar travel trailer, not this model.Photo: DanTD, CC BY-SA 4.0, via Wikimedia Commons
Grand Design · travel trailer · 26.08 ft
Imagine XLS 22MLE
6,995 lbs GVWR (max loaded)
! 4 of 6 configurations
Needs the 3.5L EcoBoost V6.
Similar cargo, not this model.Photo: DiamondBack Covers, CC BY-SA 2.0, via Flickr
Carry-On Trailer · cargo · 16 ft
6' x 12' CG7K Series 6X12CGR7K (enclosed cargo, tandem axle, ramp door)
7,000 lbs GVWR (max loaded)
! 4 of 6 configurations
Needs the 3.5L EcoBoost V6.
Similar car hauler, not this model.Photo: Strubbl, CC BY-SA 4.0, via Wikimedia Commons
Big Tex Trailers · car hauler
70CH-18 Tandem Axle Car Hauler (wood deck, 18' bed)
7,000 lbs GVWR (max loaded)
! 4 of 6 configurations
Needs the 3.5L EcoBoost V6.
Similar travel trailer, not this model.Photo: Olgierd Rudak, CC BY-SA 4.0, via Wikimedia Commons
Airstream · travel trailer · 31.17 ft
Flying Cloud 30FB Bunk
8,800 lbs GVWR (max loaded)
! 4 of 6 configurations
Needs the 3.5L EcoBoost V6.
Similar fifth wheel, not this model.Photo: Cullen328, CC BY-SA 4.0, via Wikimedia Commons
Grand Design · fifth wheel · 29.83 ft
Reflection 150-Series 260RD
9,995 lbs GVWR (max loaded)
✕ No 5th-wheel rating
Similar travel trailer, not this model.Photo: DanTD, CC BY-SA 4.0, via Wikimedia Commons
Grand Design · travel trailer · 35.42 ft
Reflection 317RSTS
10,995 lbs GVWR (max loaded)
✕ Too heavy
2 heavier trailers the Expedition isn't rated for
Similar fifth wheel, not this model.Photo: Anshamblen15, CC BY-SA 4.0, via Wikimedia Commons
Jayco · fifth wheel · 28.17 ft
Eagle Fifth Wheel 28RLT
11,400 lbs GVWR (max loaded)
✕ No 5th-wheel rating
Similar travel trailer, not this model.Photo: Anshamblen15, CC BY-SA 4.0, via Wikimedia Commons
Jayco · travel trailer · 35.5 ft
Eagle Travel Trailer 312BHOK
11,995 lbs GVWR (max loaded)
✕ Too heavy
Weights are what each trailer maker publishes (retrieved 2026-09-27). We compare the trailer's GVWR — the most it may weigh loaded — with each Expedition configuration's rating, and never a dry weight when a GVWR exists.
Fine print, made plain
What the rating assumes
Over 7,000 lbs
For trailers over 7,000 lbs. – Class IV Heavy-Duty Trailer Tow is now standard on 4x4 and requires an aftermarket weight-distributing hitch.
Hitch limit
Expedition (SWB) 4x4
7,000 lbs trailer · 700 lbs tongue · 9,600 lbs / 960 lbs with weight distribution
Hitch limit
Expedition MAX (LWB) 4x4
7,000 lbs trailer · 700 lbs tongue · 9,000 lbs / 900 lbs with weight distribution
Every rating assumes a 150-lb driver and passenger and no other cargo. Add people, gear or accessories and the trailer you can tow goes down by the same amount.
New to towing?
The five weights, in one picture
- Loaded trailer weight — must stay under the towing rating
- The rating “It assumes a towing vehicle with any mandatory options, no cargo, tongue load of 10% (conventional trailer) or king pin weight of 15% (5th-wheel trailer), and driver and passenger (150 lbs. each).” Weight of additional options, passengers, cargo and hitch must be deducted from this weight. p. 7 ↗
- Tongue weight — the part of the trailer pressing on the hitch
- “For trailers up to 2,000 lbs., tongue load not to exceed 200 lbs. For conventional trailers over 2,000 lbs., tongue load is 10% of loaded trailer weight. For 5th-wheel trailers, king pin weight is 15% of loaded trailer weight.” p. 7 ↗
- Payload — people and cargo the truck can carry
- “Payload is the combined maximum allowable weight of cargo and passengers that the vehicle is designed to carry. It is the Gross Vehicle Weight Rating minus the Base Curb Weight.” And: “When towing, trailer tongue load or king pin weight is also part of the Cargo Weight.” p. 6 ↗
- GVWR and GCWR — the two ceilings
- “Gross Vehicle Weight Rating (GVWR) is the maximum allowable weight of the fully-loaded vehicle (including passengers and cargo).” “Gross Vehicle Weight PLUS Loaded Trailer Weight EQUALS Gross Combination Weight (GCW) GCW must not exceed GCWR.” Your GVWR is on the label on the driver's door jamb. p. 6 ↗
Towing it behind a motorhome?
Can you flat tow a 2026 Ford Expedition? Some versions
Ford allows it for: Expedition / Expedition MAX 4x4.
From the maker's table
All 6 configurations
| Engine | Axle | Body | Drive | Max trailer | GCWR | Source |
|---|---|---|---|---|---|---|
| 3.5L EcoBoost V6 | 3.73 | Expedition (SWB) | 4x4 | 9,600 | 15,900 | p. 38 ↗ |
| 3.5L EcoBoost V6 | 3.73 | Expedition (SWB) | 4x4 | 9,3002 | 15,600 | p. 38 ↗ |
| 3.5L EcoBoost V6 | 3.73 | Expedition (SWB) | 4x4 | 9,2001 | 15,600 | p. 38 ↗ |
| 3.5L EcoBoost V6 | 3.73 | Expedition MAX (LWB) | 4x4 | 9,000 | 15,600 | p. 38 ↗ |
| 3.5L EcoBoost V6 | 3.31 | Expedition MAX (LWB) | 4x2 | 6,300 | 12,500 | p. 38 ↗ |
| 3.5L EcoBoost V6 | 3.31 | Expedition (SWB) | 4x2 | 6,000 | 12,000 | p. 38 ↗ |
- Equipped with 24" wheels.
- Tremor High Output engine.
Weights in lbs. “Not listed” means the maker printed no GCWR for that configuration — we don't estimate one.
More Ford towing capacities
Questions people ask
What is the towing capacity of the 2026 Ford Expedition?
From 6,000 lbs to 9,600 lbs, depending on engine, axle ratio, body and drive. The 9,600 lbs top rating is for the 3.5L EcoBoost V6 · 3.73 axle · Expedition (SWB) · 4x4 · Automatic.
Does the 2026 Ford Expedition need a tow package?
For trailers over 7,000 lbs. – Class IV Heavy-Duty Trailer Tow is now standard on 4x4 and requires an aftermarket weight-distributing hitch.
How much tongue weight can the 2026 Ford Expedition handle?
Expedition (SWB) 4x4: 700 lbs (960 lbs with a weight-distributing hitch). Expedition MAX (LWB) 4x4: 700 lbs (900 lbs with a weight-distributing hitch).
Can you flat tow a 2026 Ford Expedition?
Only some versions: Expedition / Expedition MAX 4x4.
Citing these numbers?
Can Tow That. "2026 Ford Expedition Towing Capacity." From 2026 Ford RV & Trailer Towing Guide, v1 (PDF modified 2026-03-25). https://cantowthat.com/ford/expedition
Source: 2026 Ford RV & Trailer Towing Guide (Ford Motor Company, v1 (PDF modified 2026-03-25); retrieved 2026-09-27). Page links open the PDF at the page each number is printed on.
6 ratings checked against the PDFHow we verify
