- 11,610
- Max towing, lbs
- 6,340
- Lowest rating, lbs
- 27
- Configurations
- 7
- Model years
Your exact truck
Which 1500 is yours?
Engine?
Not sure? The label on your driver's door jamb and your window sticker list these.
So far
6,340 lbs – 11,610 lbs
27 configurations still match. Answer to narrow it down.
Check your trailer →Try it
Will it pull your trailer?
Use the trailer's GVWR (on its VIN sticker) if you don't know what it weighs loaded — the dry weight leaves out water, propane and gear.
Only 26 of 27 configurations
It takes the 3.0L I6 Twin Turbo or 3.6L V6 24V VVT w/BSG or 5.7L V8 HEMI MDS VVT w/BSG or 3.0L I6 HO Twin Turbo — pick your configuration below to be sure.
▲ top rating 11,610 lbs
- Tongue weight ≈ 640 lbs — 10% of the loaded trailer, the figure Ford's towing guide uses (no more than 200 lbs up to 2,000 lbs). It counts against your payload, together with passengers and cargo.
- ✓ up to 90% of the rating · ! 90–100% (little room for cargo, hills, wind — common advice, not a Ram rule) · ✕ over the rating.
Read this before you buy
Why the numbers differ
Engine choice moves the top rating from 8,130 lbs (3.6L V6 24V VVT w/BSG) to 11,610 lbs (3.0L I6 Twin Turbo).
Same 3.0L I6 Twin Turbo Quad Cab 6'4" Box 4x2: the 3.92 axle ratio instead of 3.21 adds 3,100 lbs. p. 1 ↗
The version counts too: Limited/Longhorn is rated 880 lbs higher than RHO with everything else the same (3.0L I6 HO Twin Turbo · 3.92 axle · Crew Cab 5'7" Box · Limited/Longhorn · 4x4 · 8-Spd Auto 8HP75). p. 2 ↗
The body style counts too: Crew Cab 6'4" Box is rated 760 lbs higher than Crew Cab 5'7" Box with everything else the same (3.0L I6 HO Twin Turbo · 3.92 axle · Crew Cab 6'4" Box · Limited/Longhorn · 4x4 · 8-Spd Auto 8HP75). p. 3 ↗
The drivetrain counts too: 4x2 is rated 1,730 lbs higher than 4x4 with everything else the same (5.7L V8 HEMI MDS VVT w/BSG · 3.92 axle · Crew Cab 5'7" Box · Tradesman · 4x2 · 8-Spd Auto 8HP75). p. 1 ↗
Up 10 lbs from the 2025 model's top rating of 11,600 lbs.
In real life
What 11,610 lbs means in trailers
Ford's towing guide sorts trailers into four weight classes; the classes describe the trailer, so they apply to any tow vehicle. With the right configuration the 1500 reaches:
- Class I✓ Yes
up to 2,000 lbs
Small folding camping trailers and trailers for small boats, motorcycles and snowmobiles.
- Class II✓ Yes
2,001–3,500 lbs
Large folding camping trailers, single-axle, small- to medium-length (up to 18-ft.) trailers.
- Class III✓ Yes
3,501–5,000 lbs
Dual-axle or large single-axle travel trailers.
- Class IVUp to 11,610
over 5,000 lbs
Largest travel and 5th-wheel trailers made for recreation.
Real trailers
Can the 1500 pull these?
Similar boat package, not this model.Photo: Airman Nicole Sikorski, Public domain, via Wikimedia Commons
G3 Boats · boat package · 23 ft
Sportsman 1710 (boat + motor + trailer package)
1,865 lbs boat + motor + trailer, before fuel and gear
✓ Any configuration
Similar utility, not this model.Photo: Xaver X. Dreißig, CC BY-SA 4.0, via Wikimedia Commons
Carry-On Trailer · utility · 11.54 ft
5' x 8' GW2K Series 5X8GW2K (open utility, wood floor, gate)
2,000 lbs GVWR (max loaded)
✓ Any configuration
nuCamp · teardrop · 15.5 ft
TAB 320 (Boondock)
2,069 lbs dry weight only — loaded will be more
✓ Any configuration
Similar cargo, not this model.Photo: DiamondBack Covers, CC BY-SA 2.0, via Flickr
Carry-On Trailer · cargo · 12 ft
5' x 8' CG3K Series 5X8CG (enclosed cargo, single rear door)
2,990 lbs GVWR (max loaded)
✓ Any configuration
Similar travel trailer, not this model.Photo: Olgierd Rudak, CC BY-SA 4.0, via Wikimedia Commons
Airstream · travel trailer · 20.17 ft
Basecamp 20X
4,300 lbs GVWR (max loaded)
✓ Any configuration
Similar travel trailer, not this model.Photo: Anshamblen15, CC BY-SA 4.0, via Wikimedia Commons
Jayco · travel trailer · 20.17 ft
Jay Feather Air 16RB
4,995 lbs GVWR (max loaded)
✓ Any configuration
Similar travel trailer, not this model.Photo: Olgierd Rudak, CC BY-SA 4.0, via Wikimedia Commons
Airstream · travel trailer · 20.58 ft
Bambi 20FB
5,000 lbs GVWR (max loaded)
✓ Any configuration
Similar travel trailer, not this model.Photo: Anshamblen15, CC BY-SA 4.0, via Wikimedia Commons
Jayco · travel trailer · 29.42 ft
Jay Flight SLX 260BH
6,500 lbs GVWR (max loaded)
! 25 of 27 configurations
Needs the 3.0L I6 Twin Turbo or 3.6L V6 24V VVT w/BSG or 5.7L V8 HEMI MDS VVT w/BSG or 3.0L I6 HO Twin Turbo.
Similar travel trailer, not this model.Photo: DanTD, CC BY-SA 4.0, via Wikimedia Commons
Grand Design · travel trailer · 26.08 ft
Imagine XLS 22MLE
6,995 lbs GVWR (max loaded)
! 24 of 27 configurations
Needs the 3.0L I6 Twin Turbo or 3.6L V6 24V VVT w/BSG or 5.7L V8 HEMI MDS VVT w/BSG or 3.0L I6 HO Twin Turbo.
Similar cargo, not this model.Photo: DiamondBack Covers, CC BY-SA 2.0, via Flickr
Carry-On Trailer · cargo · 16 ft
6' x 12' CG7K Series 6X12CGR7K (enclosed cargo, tandem axle, ramp door)
7,000 lbs GVWR (max loaded)
! 24 of 27 configurations
Needs the 3.0L I6 Twin Turbo or 3.6L V6 24V VVT w/BSG or 5.7L V8 HEMI MDS VVT w/BSG or 3.0L I6 HO Twin Turbo.
Similar car hauler, not this model.Photo: Strubbl, CC BY-SA 4.0, via Wikimedia Commons
Big Tex Trailers · car hauler
70CH-18 Tandem Axle Car Hauler (wood deck, 18' bed)
7,000 lbs GVWR (max loaded)
! 24 of 27 configurations
Needs the 3.0L I6 Twin Turbo or 3.6L V6 24V VVT w/BSG or 5.7L V8 HEMI MDS VVT w/BSG or 3.0L I6 HO Twin Turbo.
Similar travel trailer, not this model.Photo: Olgierd Rudak, CC BY-SA 4.0, via Wikimedia Commons
Airstream · travel trailer · 31.17 ft
Flying Cloud 30FB Bunk
8,800 lbs GVWR (max loaded)
! 10 of 27 configurations
Needs the 3.0L I6 Twin Turbo or 5.7L V8 HEMI MDS VVT w/BSG or 3.0L I6 HO Twin Turbo.
Similar travel trailer, not this model.Photo: DanTD, CC BY-SA 4.0, via Wikimedia Commons
Grand Design · travel trailer · 35.42 ft
Reflection 317RSTS
10,995 lbs GVWR (max loaded)
! 7 of 27 configurations
Needs the 3.0L I6 Twin Turbo or 5.7L V8 HEMI MDS VVT w/BSG.
Similar fifth wheel, not this model.Photo: Cullen328, CC BY-SA 4.0, via Wikimedia Commons
Grand Design · fifth wheel · 29.83 ft
Reflection 150-Series 260RD
9,995 lbs GVWR (max loaded)
✕ No 5th-wheel rating
Similar fifth wheel, not this model.Photo: Anshamblen15, CC BY-SA 4.0, via Wikimedia Commons
Jayco · fifth wheel · 28.17 ft
Eagle Fifth Wheel 28RLT
11,400 lbs GVWR (max loaded)
✕ No 5th-wheel rating
1 heavier trailer the 1500 isn't rated for
Similar travel trailer, not this model.Photo: Anshamblen15, CC BY-SA 4.0, via Wikimedia Commons
Jayco · travel trailer · 35.5 ft
Eagle Travel Trailer 312BHOK
11,995 lbs GVWR (max loaded)
✕ Too heavy
Weights are what each trailer maker publishes (retrieved 2026-09-27). We compare the trailer's GVWR — the most it may weigh loaded — with each 1500 configuration's rating, and never a dry weight when a GVWR exists.
Compare
Towing capacity by engine
12 configurations
4 configurations
3 configurations
8 configurations
Orange = the range across that engine's configurations. Bars start at zero.
Fine print, made plain
What the rating assumes
Every rating assumes a 150-lb driver and passenger and no other cargo. Add people, gear or accessories and the trailer you can tow goes down by the same amount.
New to towing?
The five weights, in one picture
- Loaded trailer weight — must stay under the towing rating
- The rating “It assumes a towing vehicle with any mandatory options, no cargo, tongue load of 10% (conventional trailer) or king pin weight of 15% (5th-wheel trailer), and driver and passenger (150 lbs. each).” Weight of additional options, passengers, cargo and hitch must be deducted from this weight. p. 7 ↗
- Tongue weight — the part of the trailer pressing on the hitch
- “For trailers up to 2,000 lbs., tongue load not to exceed 200 lbs. For conventional trailers over 2,000 lbs., tongue load is 10% of loaded trailer weight. For 5th-wheel trailers, king pin weight is 15% of loaded trailer weight.” p. 7 ↗
- Payload — people and cargo the truck can carry
- “Payload is the combined maximum allowable weight of cargo and passengers that the vehicle is designed to carry. It is the Gross Vehicle Weight Rating minus the Base Curb Weight.” And: “When towing, trailer tongue load or king pin weight is also part of the Cargo Weight.” p. 6 ↗
- GVWR and GCWR — the two ceilings
- “Gross Vehicle Weight Rating (GVWR) is the maximum allowable weight of the fully-loaded vehicle (including passengers and cargo).” “Gross Vehicle Weight PLUS Loaded Trailer Weight EQUALS Gross Combination Weight (GCW) GCW must not exceed GCWR.” Your GVWR is on the label on the driver's door jamb. p. 6 ↗
Towing it behind a motorhome?
Can you flat tow a 2026 Ram 1500? Some versions
Ram allows it for: 4WD.
From the maker's table
All 27 configurations
| Engine | Axle | Body | Trim | Drive | Trans. | Max trailer | GCWR | Source |
|---|---|---|---|---|---|---|---|---|
| 3.0L I6 Twin Turbo | 3.92 | Quad Cab 6'4" Box | Tradesman | 4x2 | 8-Spd Auto 8HP75 | 11,610 | 17,000 | p. 1 ↗ |
| 3.0L I6 Twin Turbo | 3.92 | Crew Cab 5'7" Box | Tradesman | 4x2 | 8-Spd Auto 8HP75 | 11,490 | 17,000 | p. 1 ↗ |
| 3.0L I6 Twin Turbo | 3.92 | Crew Cab 6'4" Box | Tradesman | 4x2 | 8-Spd Auto 8HP75 | 11,420 | 17,000 | p. 2 ↗ |
| 3.0L I6 Twin Turbo | 3.92 | Quad Cab 6'4" Box | Tradesman | 4x4 | 8-Spd Auto 8HP75 | 11,370 | 17,000 | p. 1 ↗ |
| 5.7L V8 HEMI MDS VVT w/BSG | 3.92 | Crew Cab 5'7" Box | Tradesman | 4x2 | 8-Spd Auto 8HP75 | 11,320 | 17,000 | p. 1 ↗ |
| 3.0L I6 Twin Turbo | 3.92 | Crew Cab 6'4" Box | Tradesman | 4x4 | 8-Spd Auto 8HP75 | 11,220 | 17,000 | p. 2 ↗ |
| 3.0L I6 Twin Turbo | 3.92 | Crew Cab 5'7" Box | Tradesman | 4x4 | 8-Spd Auto 8HP75 | 11,200 | 17,000 | p. 2 ↗ |
| 3.0L I6 HO Twin Turbo | 3.92 | Crew Cab 6'4" Box | Limited/Longhorn | 4x4 | 8-Spd Auto 8HP75 | 10,000 | 16,220 | p. 3 ↗ |
| 5.7L V8 HEMI MDS VVT w/BSG | 3.92 | Crew Cab 5'7" Box | Tradesman | 4x4 | 8-Spd Auto 8HP75 | 9,590 | 15,850 | p. 2 ↗ |
| 3.0L I6 HO Twin Turbo | 3.92 | Crew Cab 5'7" Box | Limited/Longhorn | 4x4 | 8-Spd Auto 8HP75 | 9,240 | 15,420 | p. 2 ↗ |
| 3.0L I6 Twin Turbo | 3.21 | Quad Cab 6'4" Box | Tradesman | 4x2 | 8-Spd Auto 8HP75 | 8,510 | 13,900 | p. 1 ↗ |
| 3.0L I6 Twin Turbo | 3.21 | Crew Cab 5'7" Box | Tradesman | 4x2 | 8-Spd Auto 8HP75 | 8,390 | 13,900 | p. 1 ↗ |
Weights in lbs. “Not listed” means the maker printed no GCWR for that configuration — we don't estimate one.
More Ram towing capacities
Questions people ask
What is the towing capacity of the 2026 Ram 1500?
From 6,340 lbs to 11,610 lbs, depending on engine, axle ratio, body and drive. The 11,610 lbs top rating is for the 3.0L I6 Twin Turbo · 3.92 axle · Quad Cab 6'4" Box · Tradesman · 4x2 · 8-Spd Auto 8HP75.
Does the 2026 Ram 1500 need a tow package?
Ram's guide lists no separate package requirement for this model.
How much tongue weight can the 2026 Ram 1500 handle?
Not listed in the maker's guide.
Can you flat tow a 2026 Ram 1500?
Only some versions: 4WD.
Citing these numbers?
Can Tow That. "2026 Ram 1500 Towing Capacity." From 2026 Ram 1500 Towing Charts, PDF modified 2025-09-04. https://cantowthat.com/ram/1500
Source: 2026 Ram 1500 Towing Charts (FCA US LLC (Ram), PDF modified 2025-09-04; retrieved 2026-09-28). Page links open the PDF at the page each number is printed on.
27 ratings checked against the PDFHow we verify
